Fig. 15 Vertical installation with the wire outlet at an infinitely variable angle (complete set), see Chap.
i
wireSENSOR, WDS series
Combined installation is only possible for sensors WDS-80-MT33-P and WDS-130-MT56-P .
For WDS-40-MT19-P , the parts in the mounting bracket set can only be used individually!
Screw for installation of fastening bracket
4 through-holes
4 screws for through-holes
Sensor bracket
Fastening bracket
A 1.2
