Installation and Assembly
Fig. 4 Installation with the wire outlet at an infinitely variable angle (complete set), see Chap.
i
Additional installation options, see
Set, see Chap.
wireSENSOR, WDS series
Combined installation is only possible for sensors WDS-80-MT33-P and WDS-130-MT56-P .
A
1.2.
Fig.
4, are available in the appendix under Accessories, Mounting Bracket
Screw for installation of fastening bracket
4 through-holes
4 screws for through-holes
Sensor bracket
Fastening bracket
A 1.2
Page 15
