Service, Repair
A 1.2
The mounting bracket set provides you with various installation options, see
Fig. 11 Vertical installation with the wire outlet at a 45° angle
wireSENSOR, WDS series
Mounting Bracket Set
Screw for installation of
fastening bracket
Through-holes
2 screws for through-holes
Fastening bracket
Fig.
11, see
Fig.
12, see
Fig.
Page 25
15.
