Installation and Assembly
Fig. 7 Dimensional drawing WDS-130-MT56-P , dimensions in mm, not to scale
wireSENSOR, WDS series
14.2 (.56)
48 (1.89)
56 (2.2)
34 (1.34)
8 x M3, depth 6 mm
mounting hole
Page 18
