Smoke Control System Custom Control Equations,
Equation 51:
Manual Control SUP
Air Damper 3 Open
Equation 52:
Manual Control SUP
Air Damper 3 Close
Equation 53:
Manual Control SUP
Air Damper 4 Open
Equation 54:
Control SUP Air
Damper 4 Close
Label: MANUAL CONTROL SUP AIR DAMPER 3 OPEN
COMMENTS:
INPUTS:
The UP state of:
8-70 SWITCH Ann 1 Pt 70 Graphic LED/SW Ctlr w/32
AND the ON state of:
P273 UTILITY MASTER KEY SWITCH ENABLE
OUTPUTS:
HOLD points ON pri=5,9
M1-17 CDAMPER 3RD FLOOR SUPPLY AIR DAMPER
END:
Label: MANUAL CONTROL SUP AIR DAMPER 3 CLOSE
COMMENTS:
INPUTS:
The DOWN state of:
8-70 SWITCH Ann 1 Pt 70 Graphic LED/SW Ctlr w/32
AND the ON state of:
P273 UTILITY MASTER KEY SWITCH ENABLE
OUTPUTS:
HOLD points OFF pri=5,9
M1-17 CDAMPER 3RD FLOOR SUPPLY AIR DAMPER
END:
Label: MANUAL CONTROL SUP AIR DAMPER 4 OPEN
COMMENTS:
INPUTS:
The UP state of:
8-72 SWITCH Ann 1 Pt 72 Graphic LED/SW Ctlr w/32
AND the ON state of:
P273 UTILITY MASTER KEY SWITCH ENABLE
OUTPUTS:
HOLD points ON pri=5,9
M1-18 CDAMPER 4TH FLOOR SUPPLY AIR DAMPER
END:
Label: MANUAL CONTROL SUP AIR DAMPER 4 CLOSE
COMMENTS:
INPUTS:
The DOWN state of:
8-72 SWITCH Ann 1 Pt 72 Graphic LED/SW Ctlr w/32
AND the ON state of:
P273 UTILITY MASTER KEY SWITCH ENABLE
OUTPUTS:
HOLD points OFF pri=5,9
M1-18 CDAMPER 4TH FLOOR SUPPLY AIR DAMPER
END:
Continued
5-23
