Smoke Control System Custom Control Equations,
Equation 27:
Report TBL if
Main SUP Damper
Not Open
Equation 28:
Report TBL if Main
SUP Damper Not
Closed
Equation 29:
Report TBL if
Main RET Damper
Not Open
Equation 30:
Report TBL if Main
RET Damper Not
Closed
Label: REPORT TBL IF MAIN SUP DAMPER NOT OPEN
COMMENTS:
INPUTS:
The ON state of:
M1-12 CDAMPER MAIN OUTSIDE AIR DAMPER
DELAY for 10 sec., running timer is A266
AND NOT the ON state of:
M1-48 UTILITY MONITOR OUTSIDE AIR DAMPER OPEN
OUTPUTS:
HOLD points ON pri=9,9
P271 UTILITY MAIN SUPPLY AIR DAMPER FAIL
END:
Label: REPORT TBL IF MAIN SUP DAMPER NOT CLOSED
COMMENTS:
INPUTS:
NOT the ON state of:
M1-12 CDAMPER MAIN OUTSIDE AIR DAMPER
DELAY for 10 sec., running timer is A267
AND NOT the ON state of:
M1-49 UTILITY MONITOR OUTSIDE AIR DAMPER CLOSED
OUTPUTS:
HOLD points ON pri=9,9
P271 UTILITY MAIN SUPPLY AIR DAMPER FAIL
END:
Label: REPORT TBL IF MAIN RET DAMPER NOT OPEN
COMMENTS:
INPUTS:
The ON state of:
M1-14 CDAMPER MAIN RETURN AIR DAMPER
DELAY for 10 sec., running timer is A268
AND NOT the ON state of:
M1-45 UTILITY MONITOR MAIN RETURN AIR DAMPER OPEN
OUTPUTS:
HOLD points ON pri=9,9
P270 UTILITY MAIN RETURN AIR DAMPER FAIL
END:
Label: REPORT TBL IF MAIN RET DAMPER NOT CLOSED
COMMENTS:
INPUTS:
NOT the ON state of:
M1-14 CDAMPER MAIN RETURN AIR DAMPER
DELAY for 10 sec., running timer is A269
AND NOT the ON state of:
M1-46 UTILITY MONITOR MAIN RETURN AIR DAMPER CLOSED
OUTPUTS:
HOLD points ON pri=9,9
P270 UTILITY MAIN RETURN AIR DAMPER FAIL
END:
Continued
Equation 29
5-17
