4.4 Danfoss FC Control Profile

4.4.1 Objects in FC Profile

In FC profile, DSP 402 profile objects (6000h to 6FFFh)
cannot be used. When parameter 8-10 Control Word Profile
is set to [0] FC Profile:
•
Use object 2690h as control word, which is
parameter 16-80 Fieldbus CTW 1.
4 4
•
Use object 2692h as reference, which is
parameter 16-82 Fieldbus REF 1.
4.4.2 Control Word according to FC Profile
(Object 2690h)
Master-follower
Bit
no.: 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Illustration 4.5 Control Word
Bit Bit value = 0
00 Reference value
01 Reference value
02
03
04 Quick stop
05 Hold output
frequency
06 Ramp stop
07 No function
08 No function
09
10 Data invalid
11 No function
12 No function
13 Parameter set-up
14 Parameter set-up
15 No function
Table 4.7 Control Bits
Explanation of the control bits
Bits 00/01
Use bits 00 and 01 to select between the 4 reference
values, which are programmed in parameter 3-10 Preset
Reference according to Table 4.8.
22
CTW Speed ref.
Bit value = 1
External selection lsb
External selection msb
DC brake Ramp
Coasting No coasting
Ramp
Use ramp
Start
Reset
Jog
Ramp 1 Ramp 2
Data valid
Relay 01 active
Relay 04 active
Selection lsb
Selection msb
Reverse
Danfoss A/S © 02/2016 All rights reserved.
®
CANopen
Set-up
Table 4.8 Set-up
NOTICE
In parameter 8-56 Preset Reference Select, select how bit
00/01 gates with the corresponding function on the
digital inputs.
Bit 02, DC brake
Bit 02 = 0: Apply DC brake and stop. The braking current
and braking duration are set in parameter 2-01 DC Brake
Current and parameter 2-02 DC Braking Time.
Bit 02 = 1: Perform ramping.
Bit 03, Coasting
Bit 03 = 0: The frequency converter releases the motor
immediately (the output transistors are shut off), so that it
coasts to a standstill.
Bit 03 = 1: Enables the frequency converter to start the
motor, if the other starting conditions are fulfilled.
NOTICE
In parameter 8-50 Coasting Select, select how bit 03 gates
with the corresponding function on a digital input.
Bit 04, Quick stop
Bit 04 = 0: The frequency converter ramps the motor
speed down to a stop using parameter 3-81 Quick Stop
Ramp Time.
Bit 05, Hold output frequency
Bit 05 = 0: Freezes the current output frequency (in Hz).
The frozen output frequency can then be changed only
with digital inputs (parameter 5-10 Terminal 18 Digital Input
to parameter 5-15 Terminal 33 Digital Input) programmed to
[21] Speed up and [22] Speed down.
NOTICE
If hold output frequency is active, the frequency
converter can only be stopped by the following:
•
•
•
Bit 14
1 0
2 0
3 1
4 1
Bit 03, Coasting.
Bit 02, DC braking.
A signal on a digital input
(parameter 5-10 Terminal 18 Digital Input to
parameter 5-15 Terminal 33 Digital Input)
programmed to [5] DC-brake inverse, [2] Coast
inverse, or [3] Coast and reset inverse.
Bit 13
0
1
0
1
