Control
4.3.4 Status Word According to DSP402
Profile (Object 6041h)
Follower-master
STW
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
no.:
Illustration 4.4 Status Word
Bit Bit value = 0
00 Not ready to switch
ON
01 Switched OFF
02 Operation disabled
03 No malfunction
04 Voltage disabled
05 Quick stop
06 Switch on disable
07 No warning
Speed ≠ reference
08
09 Remote disabled
10 Setpoint not reached
11 Speed limit not
active
12
13
14
15
Table 4.6 Status Bits
Explanation of the status bits:
Bit 00, Not ready to switch on/ready to switch on
Bit 00 = 0: The state is less than ready to switch on.
Bit 00 = 1: The state is at least equal to ready to switch on.
Bit 01, Switch off/switch on
Bit 00 = 0: The state is less than switched on.
Bit 00 = 1: The state is at least equal to switched on.
Bit 02, Operation disable/operation enable
Bit 00 = 0: The state is less than operation enable.
Bit 00 = 1: The state is at least equal to operation enable.
Bit 03, No fault/trip
Bit 03 = 0: The frequency converter is not in a fault
condition.
Bit 03 = 1: The frequency converter has tripped and needs
a reset signal to run.
Bit 04, Voltage disable/voltage enable
Bit 04 = 0: Control word bit 01 = 1.
Bit 04 = 1: Control word bit 01 = 0.
MG07E102
Programming Guide
Output freq.
Bit value = 1
Ready to switch ON
Switched ON
Operation enabled
Malfunction
Voltage enabled
Run
Switch on enable
Warning
Speed = reference
Remote enabled
Setpoint reached
Speed limit active
Reserved
