Parameters
8-56 Preset Reference Select
Option: Function:
Select the trigger for the preset reference
selection.
[0] Digital A digital input triggers the preset reference
input selection.
[1] Bus A serial communication port or the fieldbus
triggers the preset reference selection.
[2] Logic AND The fieldbus/serial communication port and a
digital input trigger the preset reference
selection.
[3] Logic OR The fieldbus/serial communication port or a
*
digital input trigger the preset reference
selection.
8-90 Bus Jog 1 Speed
Range: Function:
100 RPM [ 0 - par. 4-13 Enter the jog speed. Activate this
*
RPM] fixed jog speed via the serial port
or fieldbus option.
8-91 Bus Jog 2 Speed
Range: Function:
200 RPM [ 0 - par. 4-13 Enter the jog speed. Activate this
*
RPM] fixed jog speed via the serial port
or fieldbus option.
10-01 Baud Rate Select
Select the fieldbus transmission speed. The selection must
correspond to the transmission speed of the master and the
other fieldbus nodes.
Option:
[16] 10 Kbps
[17] 20 Kbps
[18] 50 Kbps
[20] 125 Kbps
*
[21] 250 Kbps
[22] 500 Kbps
[23] 800 Kbps
[24] 1000 Kbps
10-02 Node ID
Range: Function:
127 [1 - 127] Select the station address. Every station
*
connected to the same network must have an
unambiguous address.
10-05 Readout Transmit Error Counter
Range: Function:
0 [0 - 255 ] Shows the number of CAN control transmission
*
errors since the last power-up.
MG07E102
Programming Guide
10-06 Readout Receive Error Counter
Range:
0
*
10-31 Store Data Values
Use this parameter to store changed parameter values at power-
down.
Option:
[0]
*
[2]
[3]
10-33 Store Always
Option: Function:
[0]
*
[1]
15-60 Option Mounted
Array [8]
Range:
0
*
16-84 Comm. Option STW
Range:
0
*
Function:
16-90 Alarm Word
Range:
0
*
16-91 Alarm Word 2
Shows the alarm word 2 sent via the serial communication port
in hex code.
Range:
0
*
16-92 Warning Word
Range:
0
*
Danfoss A/S © 02/2016 All rights reserved.
Function:
[0 - 255 ] Shows the number of CAN control receipt errors
since the last power-up.
Function:
Off Data values are not stored.
Store all setups Store parameter values of all set-ups. The
selection returns to [0] Off after parameter
values are stored in memory.
Store edit setup Store parameter values of the edit set-up.
The selection returns to [0] Off after
parameter values are stored in memory.
Off Deactivates non-volatile storage of data.
On Stores the received parameter data in EEPROM non-
volatile memory.
Function:
[0 - 30 ] Shows the type of the installed option.
Function:
[0 - 65535 ] Shows the status word of the extended
fieldbus communication option.
For more information, refer to the relevant
fieldbus manual.
Function:
[0 - 4294967295 ] Shows the alarm word sent via the serial
communication port in hex code.
[0 - 0xFFFFFFFFUL]
Function:
[0 - 4294967295 ] Shows the warning word sent via the
serial communication port in hex code.
