Flash Interface Registers; Flash Access Control Register (Flash_Acr) - ST STM32F205 Programming Manual

Flash memory interface
2.8

Flash interface registers

2.8.1

Flash access control register (FLASH_ACR)

The Flash access control register is used to enable/disable the acceleration features and
control the Flash memory access time according to CPU frequency.
Address offset: 0x00
Reset value: 0x0000 0000
Access: no wait state, word, half-word and byte access
31 30 29 28
15 14 13 12
DCRST ICRST
Reserved
rw
Bits 31:11 Reserved, must be kept cleared.
Bit 12 DCRST: Data cache reset
Bit 11 ICRST: Instruction cache reset
Bit 10 DCEN: Data cache enable
Bit 9 ICEN: Instruction cache enable
Bit 8 PRFTEN: Prefetch enable
Bits 7:3 Reserved, must be kept cleared.
Bits 2:0 LATENCY: Latency
20/29
27 26 25
11 10 9
DCEN ICEN
w rw rw
0: Data cache is not reset
1: Data cache is reset
This bit can be written only when the D cache is disabled.
0: Instruction cache is not reset
1: Instruction cache is reset
This bit can be written only when the I cache is disabled.
0: Data cache is disabled
1: Data cache is enabled
0: Instruction cache is disabled
1: Instruction cache is enabled
0: Prefetch is disabled
1: Prefetch is enabled
These bits represent the ratio of the CPU clock period to the Flash memory access time.
000: Zero wait state
001: One wait state
010: Two wait states
011: Three wait states
100: Four wait states
101: Five wait states
110: Six wait states
111: Seven wait states
24 23 22
Reserved
8 7 6
PRFTEN
Reserved
rw
DocID15687 Rev 5
21 20 19 18
5 4 3 2
rw
PM0059
17 16
1 0
LATENCY
rw rw
