Installing The Receiver - Seagull Models AT-6 TEXAN Assembly Manual

3
90mm.

INSTALLING THE RECEIVER.

1) Plug the six servo leads and the switch
lead into the receiver. Plug the battery pack
lead into the switch also.
2) Wrap the receiver and battery pack in
the protective foam rubber to protect them
from vibration.
3) Route the antenna in the antenna tube
inside the fuselage and secure it to the bot-
tom of fuselage using a plastic tape.
Receiver.
www.seagullmodels.com
C/A glue.
Antenna.
ATTACHMENT WING-FUSELAGE.
Bolt the to fuselage.See pictures below.
Wing bolt.
BALANCING.
1) It is critical that your airplane be balanced
correctly. Improper balance will cause your
plane to lose control and crash. The center of
60mm
gravity is locate
edge of the wing, measured at wing tip.
2) If the nose of the plane falls, the plane
is nose heavy. To correct this first move the
battery pack further back in the fuselage. If
this is not possible or does not correct it, stick
small amounts of lead weight on the fuselage
sides under the horizontal stabilizer. If the tail
of the plane falls, the plane is tail heavy.
To correct this, move the battery and receiver
forward orif this is not possible, stick weight
onto the firewall.When balanced correctly, the
airplane should sit level or slightly nose down
when you lift it up with your fingers.
back from the leading
25
