ENGINE MOUNT INSTALLATION.

See pictures below.Make yourself the
template of your engine on paper.
M4x30mm.
Mark and drill 4 holes for engine mount.
Insert 4 blind nuts to firewall.

INSTALLING THE STOPPER ASSEMBLY.

1) Using a modeling knife, carefully cut off
the rear portion of one of the 3 nylon tubes
leaving 1/2" protruding from the rear of the
stopper. This will be the fuel pick up tube.
1
www.seagullmodels.com
silicon fuel line. Connect one end of the line to
the weighted fuel pick up and the other end to
the nylon pick up tube.
at a 45º angle. This tube is the vent tube.
M4x30mm.
heat gun or lighter to permanently set the
angle of the tube.
stalled in the tank, the top of the vent tube
should rest just below the top surface of
the tank. It should not touch the top of the
tank.
tank. It may be necessary to remove some of
the flashing around the tank opening using a
modeling knife. If flashing is present, make
sure none falls into the tank.
2) Using a modeling knife, cut one length of
3) Carefully bend the second nylon tube up
4) Carefully heat the vent tube using a
Vent tube.
Fuel Fill Tube.
When the stopper assembly is in-
5) Test fit the stopper assembly into the
Fuel Pick up
Tube.
