Seagull Models AT-6 TEXAN Assembly Manual page 20

AT-6 TEXAN _
CODE SEA 110
Remove covering.
Epoxy.
When cutting through the covering to re-
move it, cut with only enough pressure
to only cut through the covering itself. Cutting
into the balsa structure may weaken it.
Put the vertical stabilizer into the in the top
of the horizontal fin. The bottom edge of the
stabilizer should also be firmly pushed against
the top of the horizontal stabilizer.
Horizontal 90º
Stabilizer.
80mm.
80mm.
Wire keeper.
20
.
Vertical
Stabilizer.
INSTALLATION THE PUSHROD.
Trim and cut.
Hinge.
90mm.
8mm.
8mm.
M2 Lock nut.
M2 clevis.
Attach to servo arm in fuselage.
C/A glue.
Epoxy.
