Barcode Scanner - 2D Barcodes

The Linea Pro 7 2D model uses a scan engine that supports one-dimensional (1D) and two-
dimensional (2D) barcode symbols. The effective reading distance of the barcode reader varies
depending on the barcode size.
To Scan a 2D Barcode:
1. Activate the Linea Pro 7 by pressing either Scan Button.
2. Position the scan head so that the pointer is aimed at the barcode, and the barcode is within the
width of the red illumination box.
3. Slowly pull the unit back, gradually increasing the distance between the barcode and scanner,
until the barcode has been read by the scanner.
Linea Pro 7 User Manual
UM-00028 Version: A
Figure 11: 2D Barcode Scanning
15-20 cm
