CHARGING YOUR LINEA PRO 7

Charging the Linea Pro 7 through the USB Port

The Linea Pro 7 uses a Lithium ion rechargeable battery and supports two modes for charging.
• Default Mode: Charging time is approximately 3h and 40min
• Slow Charging Mode: Charging time is approximately 6h
The Linea Pro 7 also supports pass through charging to the iOS device. The iPhone and Linea Pro 7
may be charged together via the USB Type-C port or by placing it in a Linea Pro 7 Single or 5-Unit
Charging Station. Due to current charging limitations, the Linea Pro 7 should not be charged via USB
from a PC/Mac connection.
To Charge the Linea Pro 7:
1. Connect the USB Type-C charger cable to the USB port (shown in the figure below).
The battery should be charged in an ambient operating temperature of -10°C to +40°C.
If the device is equipped with encrypted magnetic stripe reader, do not allow the battery to fully dis-
charge. The device will disconnect from the iPhone when the battery is drained below 3.6V.
To prevent electrical damage to the Linea Pro 7 and/or battery, please use approved USB
Type-C charger cables only.
Linea Pro 7 User Manual
UM-00028 Version: A
USB Sync/Charge Port
Figure 7: USB Type-C Sync/Charge Port
Page 11 of 30
