Linēa-pro 4 User Manual v1.00
Linēa-pro 4
. . . . . . . . . . . . . . . . . . . .
User Manual
Advertisement
Table of Contents
Related Manuals for Infinite Peripherals PRO 4
Summary of Contents for Infinite Peripherals PRO 4
- Page 1 Apple Inc. Infinite Peripherals, Inc. www.ipcprint.com Linēa-pro 4 User Manual v1.00 Linēa-pro 4 User Manual ....
-
Page 2: Legal Notice
Made for iPod touch 4th generation iPhone 4 Infinite Peripherals, Inc. www.ipcprint.com Linēa-pro 4 User Manual v1.00 ....Page 2... - Page 3 Linēa-pro 4 User Manual v1.00 Description Linea-pro 4 with 3-Track mag-stripe reader Linea-pro 4 with 3-Track mag-stripe reader and 1D barcode scanner Linea-pro 4 with 3-Track mag-stripe reader and 2D barcode scanner Linea-pro 4 with 3-Track mag-stripe reader and 1D barcode scanner and Bluetooth®...
-
Page 4: Table Of Contents
Overview ... 5 Technical Data ... 6 Box Contents ... 7 Getting Started ... 8 About Your Linēa-pro 4 ... 9 Charging Battery ... 11 Status & Operating Modes ... 12 Attaching Device ... 13 1D Barcode Scanning ... 14 2D Barcode Scanning ... -
Page 5: Overview
Overview Linēa-pro 4 allows mobile workers to convert their iPod touch and iPhone handset into a powerful point-of-sale solution. The Linēa-pro 4 includes optional 1D or 2D barcode scanner, 3-tracks magnetic stripe reader, and a rechargeable battery extender in a very compact and durable protective case. -
Page 6: Technical Data
Technical Data General Specifications: Power supply Internal voltage 3.3V & 5V Active (turn on Linea-pro 4) / Active with Scanning / Stand By (after 5sec Operation Modes without operate) Hitachi - HD64F3687 Memory 512k I2C EEPROM memory - for Linea-pro 4 settings RS232 Interface - communication between Linea-pro 4 &... -
Page 7: Box Contents
Box Contents Your IPC Linēa-pro 4 comes with the following items listed below: Item Part Number Linea-pro 4 CABDAT001240 Linēa-pro 4 User Manual *Bulk Shipments may ship without cables and manuals in each box. Software ( Drivers & SDK ): Because of the continually evolving SDK, the latest SDK are not distributed on CD. -
Page 8: Getting Started
Getting Started The IPC Linēa-pro 4 allows you to scan barcode and capture Magnetic Strip information onto your iPod and iPhone. Before using your Linēa- pro 4 the battery should be properly charged. The following Quick Start guide will help to get your Linēa-pro 4 ready for use. -
Page 9: About Your Linēa-Pro 4
About Your Linēa-pro 4 Linēa-pro 4 (Right side) On/Off Scan Engine Linēa-pro 4 (Left side) USB Sync / Charge Port Scan Button Infinite Peripherals, Inc. www.ipcprint.com Linēa-pro 4 User Manual v1.00 Volume Controls Figure 1 Audio Connector Figure 2 . - Page 10 Special software must be used to process the information captured by the barcode scanner and magnetic strip reading feature. consult your reseller for this software or contact Infinite Peripherals for recommendations on compatible third party software solutions. Infinite Peripherals, Inc.
-
Page 11: Charging Battery
Charging Battery Charging the Linēa-pro 4: The Linēa-pro 4 uses a Lithium Ion rechargeable battery pack. Before first use, the battery pack should be charged for at least (4) hours. To prevent electrical damage to the Linēa-pro 4 and/or battery pack, please use approved USB to Mini USB cables only. -
Page 12: Status & Operating Modes
Status & Operating Modes The Linēa-pro 4 uses the battery indicator LEDs to indicate various conditions of operation. Possible LED lighting indications may result from charging, active/online status, or because of low battery. following table and figure explain these conditions and LED indication. -
Page 13: Attaching Device
Attaching Device When using the Linēa-pro 4, care must be taken to ensure the Linēa-pro 4 30 pin connector and the iPod and iPhone connector are not accidentally damaged. The figures below show how to attach your device to the Linēa-pro 4. -
Page 14: 1D Barcode Scanning
1D Barcode Scanning Using the 1D barcode scanner: The Linēa-pro 4 1D uses a scan engine that supports one-dimensional (1D) barcode symbols. The effective reading distance of the barcode reader varies depending on the barcode size. Scanning 1D Barcodes: To scan a 1D barcode fist activate the scanner. Then position the scan head as close to the barcode label as possible so that the scan line crosses both ends of the barcode as shown in the figure below. -
Page 15: Barcode Scanning
2D Barcode Scanning Using the 2D barcode scanner: The Linēa-pro 4 2D uses a scan engine that supports one-dimensional (1D) and two-dimensional (2D) barcode symbols. The effective reading distance of the barcode reader varies depending on the barcode size. Scanning 2D Barcodes: To scan a 2D barcode fist activate the scanner. -
Page 16: Card Reading
Card Reading Reading Magnetic Strips: The Linēa-pro 4 has a built-in magnetic card reader. The card reader incorporates a (3) track magnetic read head requiring a single swipe to read field data from all three tracks. The magnetic read head faces up towards the top of the cradle. When placing the card into the reader, the magnetic strip must be facing up as shown in the figure below. -
Page 17: Replacing Battery
Replacing Battery To replace the Linēa-pro 4 battery, follow the steps below. Remove the device as shown in the figure below. Figure 13 Squeeze battery cover latch to the left as shown in the figure above. Figure 14 Lift the battery cover as shown in the figure above. Remove the existing Battery pack. -
Page 18: Syncing
To sync iPod with iTunes through the Linēa-pro 4 follow the steps below; Connect the Linēa-pro 4 to a computer using a Mini USB cable as shown in the figure below. Wait for the sync mode 2-beeps and the center LED flashes green. -
Page 19: Developing Solutions
Linēa-pro 4 SDK. developing application to use the barcode scanning and card reading capability of the Linēa-pro 4. For details on using the Linēa-pro 4 SDK, please refer to the SDK’s documentation. For the latest Linēa-pro 4 SDK’s, please visit our Linēa-pro developer portal: Infinite Peripherals, Inc. -
Page 20: Troubleshooting
Infinite Peripherals, Inc. www.ipcprint.com Linēa-pro 4 User Manual v1.00 Possible Cause * Linēa-pro 4 not turned On. * Card inserted incorrectly. * Swipe method incorrect. * Faulty read head. * Unreadable magnetic strip. * Swipe method incorrect. -
Page 21: Barcode Scanning
Linēa-pro 4 User Manual v1.00 Possible Cause * Linēa-pro 4 battery is to low. * Linēa-pro 4 not turned on by software. * Faulty scan engine. * Unreadable barcode. * Linēa-pro 4 battery is to low. * Faulty scan engine. -
Page 22: Federal Communications Commission
2) this device must accept any interference, including interference that may cause undesired operation of the device. Infinite Peripherals, Inc. www.ipcprint.com Linēa-pro 4 User Manual v1.00 interference ....radio communications. - Page 23 This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Infinite Peripherals, Inc. www.ipcprint.com Linēa-pro 4 User Manual v1.00 instructions ....satisfying...
-
Page 24: Contact Information
Contact Information National Sales Headquarters: HQ and Main Distribution Facility: Technical Support: Infinite Peripherals, Inc. www.ipcprint.com Linēa-pro 4 User Manual v1.00 Infinite Peripherals, Inc. 1124 Main Street Suite B Irvine, CA 92614 Toll Free: 866-278-7860 Phone: 949-222-0300 Fax: 949-222-0375 www.ipcprint.com MobileSales@ipcprint.com...
