SERVICING YOUR LINEA PRO 7

Battery Replacement

The Linea Pro 7 is designed with a user replaceable 2100mAh battery.
To Replace the Battery:
1. Using a T5 x 40mm Torx Driver, remove the torx screw from the back cover.
2. Gently pull tab in then up to remove back cover.
3. Lift up on battery to remove, then insert replacement battery ensuring battery contacts are
aligned.
4. Replace battery cover, then insert the (2) torx screws into place and tighten using the torx driver.
Battery Cover
Torx Screw
T5 x 40mm Torx Driver not included.
Linea Pro 7 with encrypted functionality has special key protection features. If battery
is removed from the unit for more than one (1) hour, it may result in the erasure of the
encryption key and disabling of the card reading features. See SRED Encrypted MSR
Information below for additional information.
Linea Pro 7 User Manual
UM-00028 Version: A
Figure 16: Battery Replacement
