ASSEMBLING YOUR LINEA PRO 7
To Assemble the Linea Pro 7:
1.
Push the top cover forward, then up to insert the iOS device.
2. Connect the iOS device by firmly sliding it onto the Lightning™ Connector.
3. Tilt the top cover down and slide it back until it clicks into place.
To secure the Linea Pro 7 insert the (2) torx screws, provided with the device, on the backside side of
the unit near the top.
Top Cover
Figure 6: Linea Pro 7 Assembly
Linea Pro 7 User Manual
Page 10 of 30
UM-00028 Version: A
