ASSEMBLING YOUR LINEA PRO 7 PLUS
1.
Remove the top cover by unscrewing 4 screws, and then slide the
unit forward and lift it up.
2.
Attach the iOS device to the Lightning™ connector by firmly sliding
it into place.
3.
Align the front cover with the two hooks, and slide it down and then
back until it clicks into place.
4.
Tighten all four screws on the back cover to further secure the top
cover.
To remove the iOS device, first loosen and then remove the four screws.
Page 11
