Reference Information; Painting The Speaker Grille - Extron electronics SF 26CT User Manual

Reference
Information
This section covers the following topics:
•
•

Painting the Speaker Grille

The speaker grille can be painted using spray paint. Ensure that the spray paint adheres to
both metal and plastic.
NOTE: Extron is not responsible for any alterations to the original paint.
To paint the grille:
1.
2.
3.
4.
5.
6.
Painting the Speaker Grille
Troubleshooting
Remove the grille from the speaker.
Figure 28. SF 26CT Speaker Grille
Remove and set aside the scrim from the back side of the grille.
Spray paint the front side of the grille.
NOTES:
•
Do not paint the back side of the grille.
•
Apply an even coat across the entire front surface.
•
Be sure not to clog the grille holes.
Wait for the paint to dry.
Reattach the scrim to the back of the grille.
Reattach the grille to the speaker.
Speaker Grille
SF 26CT User Guide • Reference Information 22
