Danfoss PVG 16 Technical Information page 99

Technical Information
PVG 16 Proportional Valve Group
PVG 16 Combinations Valve Stack Dimensions
© Danfoss | December 2018
PVB 32/16 combination valve stack dimensions, mm [in] (continued)
Number
of PVB 32
1 2
(down)
9
L1 506 546
[19.92] [21.50]
L2 576 622
[22.68] [24.49]
10
L1 554 594
[21.81] [23.39]
L2 622 670
[24.49] [26.38]
11 L1 602 -
[23.70]
L2 670 -
[26.38]
Weight for a PVG 32/16 valve stack
The combined weight of a PVG 32/16 valve stack can be defined like this:
(Numbers of PVB 32 x 4,42) + (numbers of PVB 16 x 3,67) + 3,6 = Weight in kg
(Numbers of PVB 32 x 9.75) + (numbers of PVB 16 x 8.09) + 7.95 = Weight in lb
Number of PVB 16 modules
3 4 5 6
586 - - -
[23.07]
646 - - -
[25.43]
- - - -
- - - -
- - - -
- - - -
7 8 9 10
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
BC00000211en-000901 | 99
