PVG 16 Proportional Valve Group
PVP Inlet Modules
Part numbers for Open Center PVP with PPRV
Part number Actuation P-port
PVE G1/2"
157B5010
PVE G1/2"
157B5012
PVE G3/4"
157B5110
PVE G3/4"
157B5112
PVE G3/4"
157B5180
PVH/PVHC G3/4"
157B5190
PVE 7/8-14 UNF
157B5210
PVE 7/8-14 UNF
157B5212
PVE 1 1/16-12 UNF 1 1/16-12 UNF 1/2-20 UNF
157B5310
PVE 1 1/16-12 UNF 1 1/16-12 UNF 1/2-20 UNF
157B5312
PVE 1 1/16-12 UNF 1 1/16-12 UNF 9/16-18 UNF
157B5380
PVH/PVHC 1 1/16-12 UNF 1 1/16-12 UNF 9/16-18 UNF
157B5390
PVE G3/4
11008850
1 PVE G3/4
11013317
PVE 1 1/16-12 UNF 1 1/16-12 UNF 1/2-20 UNF
11020964
1 PVH/PVHC G3/4
11087590
PVE JIS 3/4
11090453
2 PVE G3/4
11119429
PVH/PVHC G3/4
11124965
PVH/PVHC G3/4
11124966
2 PVE 1 1/16-12 UNF 1 1/16-12 UNF 9/16-18 UNF
11130941
PVH/PVHC 1 1/16-12 UNF 1 1/16-12 UNF 1/2-20 UNF
11167773
PVE G1/2
11187356
PVH/PVHC G1/2
11190123
PVE G3/4
11196947
PVE 1 1/16-12 UNF 1 1/16-12 UNF 9/16-18 UNF
11225941
3 PVE G3/4
157B5135
2 PVE G3/4
157B5904
PVE JIS 1/2
157B5923
PVE JIS 3/4
157B5926
PVE G3/4
157B5934
2 PVH/PVHC G3/4
157B5943
2 PVE G3/4
157B5953
PVE G3/4
157B5954
PVE 1 1/16-12 UNF 1 1/16-12 UNF 9/16-18 UNF
157B5960
PVE G3/4
157B5966
PVE G3/4
157B5976
© Danfoss | December 2018
T-port LS-port
G3/4" G1/4"
G3/4" G1/4"
G3/4" G1/4"
G3/4" G1/4"
G3/4" G1/4"
G3/4" G1/4"
1 1/16-12 UNF 1/2-20 UNF
1 1/16-12 UNF 1/2-20 UNF
G3/4 G1/4
G3/4 G1/4
G3/4 G1/4
JIS 3/4 JIS 1/4
G3/4 G1/4
G3/4 G1/4
G3/4 G1/4
G3/4 G1/4
G3/4 G1/4
G3/4 G1/4
G3/4 G1/4
G3/4 G1/4
JIS 3/4 JIS 1/4
JIS 3/4 JIS 1/4
G3/4 G1/4
G3/4 G1/4
G3/4 G1/4
G3/4 G1/4
G3/4 G1/4
G3/4 G1/4
M-port Pp-port
G1/4" -
G1/4" -
G1/4" -
G1/4" -
G1/4" G1/4"
G1/4" G1/4"
1/2-20 UNF -
1/2-20 UNF -
1/2-20 UNF -
1/2-20 UNF -
9/16-18 UNF 9/16-18 UNF
9/16-18 UNF 9/16-18 UNF
G1/4 -
G1/4 G1/4
1/2-20 UNF -
G1/4 G1/4
JIS 1/4 JIS 1/4
G1/4 G1/4
G1/4 G1/4
G1/4 G1/4
9/16-18 UNF 9/16-18 UNF
1/2-20 UNF -
G1/4 -
G1/4 -
G1/4 -
9/16-18 UNF 9/16-18 UNF
G1/4 G1/4
G1/4 G1/4
JIS 1/4 -
JIS 1/4 -
G1/4 -
G1/4 G1/4
G1/4 -
G1/4 G1/4
9/16-18 UNF -
G1/4 -
G1/4 -
T0-port Mounting PVPX
- M8 -
- M8 Yes
- M8 -
- M8 Yes
- M8 -
- M8 -
- 5/16-18 UNC -
- 5/16-18 UNC Yes
- 5/16-18 UNC -
- 5/16-18 UNC Yes
- 5/16-18 UNC -
- 5/16-18 UNC -
- M8 Yes
G1/4 M8 -
- M8 -
- M8 -
JIS 1/4 M8 -
- M8 -
- M8 Yes
- M8 -
- 5/16-18 UNC -
- 5/16-18 UNC Yes
- M8 Yes
- M8 Yes
G1/4 M8 -
9/16-18 5/16-18 UNC -
UNF
G1/4 M8 -
- M8 -
- M8 -
- M8 -
- M8 -
- M8 -
- M8 Yes
- M8 -
9/16-18 5/16-18 UNF -
UNF
- M8 Yes
- M8 Yes
BC00000211en-000901 | 15
*
