Technical Information
PVG 16 Proportional Valve Group
PVG 16 Actuation

PVG 16 connector variants

Pin connector
1 x 4 DEUTSCH
2 3
1 4
© Danfoss | December 2018
PVG 16 connector variants for PVEO, PVEA, PVEO-CI, PVEA-CI, PVEA-F with pin layout information.
2 x 4 DEUTSCH
Pin layout for PVEO, PVEA, PVEO-CI, PVEA-CI
PVE Type
PVEO
PVEA
PVEO-CI, PVEA-CI
Pin layout for PVEA-F
Connector Pin 1
1 x 6 DEUTSCH Vi
4 1
3 2
2 3
1 4
Connector Pin 1
1 x 4 DEUTSCH NC2
1 x 4 DEUTSCH Vi
2 x 4 DEUTSCH CAN_H
Pin 2 Pin 3
NC Vf
1 x 6 DEUTSCH
3 4
2 5
1 6
Pin 2 Pin 3
Vneg Vneg
SP Vneg
CAN_L Vbat
Pin 4 Pin 5
SP Vneg
BC00000211en-000901 | 83
Pin 4
NC4
Vbat
Vneg
Pin 6
Vbat
