Technical Information
PVG 16 Proportional Valve Group
General Information
PVG 16 Modules Overview
PVG 16 Modules Assembly Overview
PVM
8 |
©
Danfoss | December 2018
PVG proportional valve group shown in the exploded view illustration for a quick modules navigation.
PVBS
PVG Modules Navigation:
PVP Inlet Modules
on page 9
PVB Basic Modules
on page 38
PVBS Main Spools
on page 62
PVM Manual Actuation
on page 69
PVE Electro-hydraulic Actuation
PVH Hydraulic Actuation
on page 71
PVHC Electro-Hydraulic Actuation
PVS End Plates
on page 86
PVAS Stay Bolts
on page 92
PVP
PVB
PVS
PVAS
on page 75
on page 73
PVE
PVH/Covers
PVHC
BC00000211en-000901
