PVG 16 Proportional Valve Group
PVS End Plates

PVS/PVSI with LX-connection

88 | © Danfoss | December 2018
The PVG 16 PVS end plates are placed at the end the valve stack section. Furthermore, the end plate is
ensuring Load Sense (LS) is relieved to tank pressure when the valve is not operated. The LX port enables
other remote valves to be connected onto the Load Sense shuttle network.
The PVS type end plates are made of aluminum while the PVSI types are made of cast iron thereby being
able to withstand a higher pressure.
The PVS/PVSI with LX-port connection features:
•
Integrated LS pressure relief valve to tank
•
Threaded LX port for connecting another valve to LS network
PVS/PVSI with LX-connection
PVS/PVSI with LX-connection schematic
Lx
See part number table for details on maximum pressure capacity
Technical specification for A/B-port
Max. continuous pressure
380 bar [5510 psi]
Technical specification
Parameter
Fluid temperature
Fluid viscosity
Fluid cleanliness
Operating temperature
Part numbers for PVS/PVSI with LX-port connection
Part number Max. pressure
157B2005
157B2015
350 bar 5076 psi]
157B2910
PVS/PVSI with LX-connection dimensions
Max. intermittent pressure
420 bar [6090 psi]
Minimum Recommended range
-30°C [-22°F] 30 to 60°C [86 to 140°F]
2
4 mm /s [39 SUS] 12 to 75 mm
23/19/16 (according to ISO 4406)
Ambient: -30 to 60°C [-22 to 140°F]
Material Weight kg [lb]
Cast iron 1.695 [3.74]
LX
G1/8
11.5 [0.45] 95 [3.74]
23 [0.9] 110 [4.33]
Max. rated flow
65 l/min [17 US gal/min]
Maximum
90° [194°F]
2 2
/s [65 to 347 SUS] 460 mm /s [2128 SUS]
LX port Mounting
1/2-20 UNF 5/16-18 UNC
G1/4"
M8
M12x1.5 ISO 6149
