Technical data (continued)
Fluid consumption
Fluid temperature
Fluid viscosity
Fluid cleanliness
LED characteristic
Color
Green constant
Green flashing @ 1.5 Hz
Red constant
Red flashing @ 1.5 Hz
Part numbers for PVEA/PVEA-F/PVEA-CI
Part number Type
PVEA
11103692
PVEA-F
11106795
PVEA-CI
11121945
PVEA-CI
11149437
Neutral
Locked position
Actuating
Ambient Storage
Ambient Operating
Operating range
Minimum
Maximum
Minimum
LED characteristic
Connector Protection Class
1x4 DEUTSCH IP 67
1x4 DEUTSCH IP 67
1x4 DEUTSCH IP 67
1x4 DEUTSCH IP 67
0.04 l/min [0.01 US gal/min]
0.04 l/min [0.01 US gal/min]
0.6 l/min [0.16 US gal/min]
-50 to +90°C [-58 to +194°F]
-40 to +90°C [-40 to +194°F]
2
12 to 75 mm /sec [65 to 347 SUS]
2
4 mm /sec [39 SUS]
2
460 mm /sec [2128 SUS]
18/16/13 (according to ISO 4406)
Description
No error – Actuating
Neutral – Power save
Internal error
External or Float error
Interface Functionality
— Standard
— Float B-port
J1939/ISObus Standard
CANopen Standard
