Technical Information
PVG 16 Proportional Valve Group
PVG 16 Combinations Valve Stack Dimensions
©
Danfoss | December 2018
Weight for a PVG 256/16 valve stack
The combined weight of a PVG 256/16 valve stack can be defined like this:
(Numbers of PVB 256 x 20.9) + (numbers of PVB 16 x 3,67) + 17.5 = Weight in kg
(Numbers of PVB 256 x 40.08) + (numbers of PVB 16 x 8.09) + 38.6 = Weight in lb
BC00000211en-000901 | 107
