Pin Signal
6 NC
7 CSI0_CLK-
8 NC
9 CSI0_CLK+
10 GND
11
CSI0_RX1-
12 CAM_XCLK_1V8_CAM1
13
CSI0_RX1+
14 V_1V8_S0
15 V_1V5_CAM
16
NC
17 CSIO_P1_PWDN_1V8
18 NC
19 CAM_RST_1V8#
20
I2C1_SCL_1V8_CAM1
21 V_2V8_CAM
22 I2C1_SDA_1V8_CAM1
23 GND
24 NC

Table 28: Pin Assignment (J6)

Pin Signal
1 NC
2 2V8_CAM
3 CSI2_RX0-
4
NC
5 CSI2_RX0+
6
NC
7 CSI2_CLK-
8 NC
9 CSI2_CLK+
10 GND
11 CSI2_RX1-
12 CAM_XCLK_1V8_CAM2
13 CSI2_RX1+
14 V_1V8_S0
15 V_1V5_CAM
16 NC
17
CSI_P2_PWDN_1V8
18 NC
