Kontron pITX-iMX8M User Manual page 41

Pin Signal
6 +1.5V
7 CLKREQ#
8
UIM_PWR
9 GND
10
UIM_DATA
11 PCIE_mini CLK#
12 UIM_CLK
13 PCIE_mini CLK
14 UIM_RESET
15 GND
16 UIM_VPP
17 UIM_IC_DM
18
GND
19 UIM_IC_DP
20 W_Disable#
21 GND
22 RST#
23 PCIE_RX-/SATA_RX-
24 +3V3
25 PCIE_RX+/SATA_RX+
26
GND
27 GND
28
+1.5 V
29 GND
30 SMB_CLK
31 PCIE_TX-/SATA_TX-
32 SMB_DATA
33 PCIE_TX+/SATA_TX+
34 GND
35 GND
36
USBhub_D1_N
37 GND
38 USBhub_D1_P
39 +3V3
40 GND
41 +3V3
42 NC
43 SATA_DET5#
44
NC
45 NC
46
NC
47 NC
Type
PWR
PWR
PWR
NC
NC
NC
PWR
NC
NC
PWR
PWR
PWR
PWR
PWR
PWR
PWR
PWR
PWR
IO
PWR
IO
PWR
PWR
PWR
NC
NC
NC
NC
NC
