Sub-Screen Function
OS Selection [Windows 10 (Ver>=167)]
PCI Clock Run [Enable]
Real Time Option [RT Disable]
GOP Configuration
Uncore
GOP Driver [Enable]
Configuration
Intel Graphics Pei Display PEIM [Disable]
GOP Brightness Level [140]
IGD Configuration
Integrated Graphics Device [Enable]
Primary Display [IGD]
RC6 (Render Standby) [Disable]
GTT Size [8MB]
Aperture Size [256MB]
DVMT Pre-Allocated [64M]
DVMT Total Gfx Mem [256M]
Cd Clock Frequency [624 MHz]
GT PM Support [Enable]
PAVP Enable [Enable]
IGD – LCD Control
BIA [Auto]
ALS Support [Enable]
IGD Flat Panel [Auto]
IGD Boot Type [Auto]
Panel scaling [Auto]
GMCH BLC Control [PWM-Inverted]
HD-Audio Configuration >
South Cluster
Configuration
LPSS Configuration >
PCI Express Configuration >
Second level Sub-Screen / Description
HD-Audio Support [Enable]
Low Power Sub System
LPSS HSUART #3 Support (D24:F2) [Enable]
LPSS SPI #1 Support (D25:F0) [Enable]
LPSS IOSF PMCTL SOix Enable [Enable]
PCI Express Configuration
PCI Express Clock Gating [Enable]
Port8xh Decode [Disable]
Peer Memory Write Enable [Disable]
Compliance Mode [Disable]
> PCIe #0 BDF[00:13:00] LAN 1
> PCIe #1 BDF[00:13:01] mPCIe
When PCIE #X is enabled:
PCIe #X BDF[XX:XX:XX] [Auto]
ASPM [Disable]
L1 Substates [L1.1 & L1.2]
ACS [Enable]
URR [Disable]
FER [Disable]
NFER [Disable]
CER [Disable]
CTO [Default Setting]
SEFE [Disable]
SENFE [Disable]
SECE [Disable]
PME SCI [Enable]
Hot Plug [Disable]
PCIE Speed [Auto]
Transmitter Half Swing [Disable]
Extra Bus Reserved 0
Reserved Memory 10
Reserved I/O 4
