4.2. Environmental Conditions

Table 4: Environmental Conditions

Storage IEC 60068-2-1 60068-2-2 -40°C to +85°C
Temperature
Operating IEC 60068-2-1 60068-2-2 -40°C to +85°C for Extended Consumer Variants 0°C to +60°C for
Temperature Commercial Temperature Variants
Humidity IEC 60068-2-78 50% to 95% Relative Humidity at 25°C to 30°C, non- condensing
RoHS
RoHS II compliant
REACH Compliance
Regulation (EC) No 1907/2006
EMC and EMI EN55022 [Must compliance with no deviation allowed] Class B radiated and conducted
EN 61000-6-3:2007 [Must compliance with no deviation allowed]
(EMC) Generic emission standard Part 6-4: Emission standard for commercial
environments
IEC 61000 PT4-2, (EN 61000-4-2) Electrostatic discharge immunity ESD
IEC 61000 PT4-3, (EN 61000-4-3 and ENV 50204) Radiated
Field
IEC 61000 PT4-4, (EN 61000-4-4) Electrical fast transient/burst (EFT) BURST
IEC 61000 PT4-5, (EN 61000-4-5) Surge immunity test
IEC 61000 PT4-6, (EN 61000-4-6) Immunity to conducted disturbances
IEC 61000 PT4-8, (EN 61000-4-8) Immunity to magnetic fields (LOW)
IEC 61000 PT4-11, (EN 61000-4-11) Testing and measuring techniques-voltage dips, short
interruption, and voltage variations immunity tests
Safety EN 62368-1
Safety for information technology equipment including electrical business equipment
Altitude 2000m max
Shock IEC 60068-2-27
Half-sine wave, Acceleration: 2g Pulse duration: 11ms
Number of shocks: 600 shocks (100 shocks for each face)
Vibration IEC 60068-2-64
Test Fh, Random Vibration, 90 min per axis, 3 axes at 1.9 grms, with PSD: 10-20Hz: 0.05
g²/Hz and 20-500 Hz:- 3dB/octave.
Reliability 5 years x 365 days x 24 hours
including MTBF The MTBF value according to Telcordia standard
Power Supply Specifications
Voltage Ripple Voltage Ripple maximum 100 mV peak to peak 0-20 MHz
Rise Time 2 ms to 20 ms rise time from input voltage <10% to nominal VCC
