  • Page 1 mITX-E38 (Thin Mini-ITX size) KTD-N0903-C The pulse of innovation...

  • Page 2: Table Of Contents

    Error! Use the Home tab to apply Überschrift 1 to the text that you want to appear here. Table of Contents » Table of Contents « Introduction ................... 5 Installation Procedure ................6 Installing the Board ........................ 6 Requirements IEC60950 ......................7 System Specifications ................
  • Page 3 Advanced ..........................47 CPU Configuration ............................ 48 Uncore Configuration ..........................50 LAN Configuration ............................ 52 Hardware Health Configuration ........................53 Kontron Configuration ..........................55 Display Configuration ..........................56 System Components ..........................57 South Cluster Configuration........................58 USB Configuration ............................ 60 Audio Configuration ..........................

  • Page 4: Document Revision History

    Brand and product names are trademarks or registered trademarks of their respective owners. Disclaimer KONTRON Technology A/S reserves the right to make changes without notice to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance.

  • Page 5: Life Support Policy

    Warranty KONTRON Technology warrants its products to be free from defects in material and workmanship during the warranty period. If a product proves to be defective in material or workmanship during the warranty period KONTRON Technology will, at its sole option, repair or replace the product with a similar product.
  • Page 6 2. Driver Version numbers (Graphics, Network, and Audio). 3. Attached Hardware: Harddisks, CD-Rom, LCD Panels etc. If the Kontron Technology product seems to be defect and you want to return it for repair, please follow the guide lines from the following page: http://kontron.com/services/rma-information/kontron-technology-a-s/...

  • Page 7: Introduction

    Introduction Introduction This manual describes the mITX-E38 boards made by KONTRON Technology A/S. The boards will also be denoted E38. The E38 boards are based on Intel Atom E38xx SOC (System On Chip) and will be available in three versions having 1, 2 or 4 cores. The differences between the three types of boards are listed in this...

  • Page 8: Installation Procedure

    Installation Procedure Installing the Board To get the board running follow these steps. If the board shipped from KONTRON has already components like RAM and CPU cooler mounted, then relevant steps below can be skipped. 1. Turn off the PSU (Power Supply Unit) Warning: Turn off PSU (Power Supply Unit) completely (no mains power connected to the PSU) or leave the Power Connectors unconnected while configuring the board.

  • Page 9: Requirements Iec60950

    KTD-N0903-C Page 7 Installation Procedure 8. Mounting the board in chassis Warning: When mounting the board to chassis etc. please notice that the board contains components on both sides of the PCB which can easily be damaged if board is handled without reasonable care.

  • Page 10: System Specifications

    E3845 (4 core), 1,91GHz, 10W Memory 1x DDR3L SODIMM socket supporting single-channel unbuffered DDR3L 1066/1333MHz (PC3-8500/10600). pITX-E3815/E3826 supports only DDR3-1066MHz. Up to 4GB (Intel specification) however Kontron has qualified 8GB. (ECC not supported). Flash eMMC 16GB TLC Nand. E3845 only. SD card slot 1x SD Card Slot, SD Card 3.0 interface.
  • Page 11 Note that Intel specifies that battery must be connected, however it is unspecified what is the risk of not using battery. When battery is not connected, Kontron has not been able to find any problems except for RTC not running.
  • Page 12 -20°C – 70°C; lower limit of storage temperature is defined by specification restriction of on-board CR2032 battery. Board with battery has been verified for storage temperature down to -40°C by Kontron. 5% - 95% relative humidity (non-condensing) Electro Static Discharge (ESD) / Radiated Emissions (EMI): All Peripheral interfaces intended for connection to external equipment are ESD/ EMI protected.

  • Page 13: System Overview

    KTD-N0903-C Page 11 System Specification System overview The block diagram below shows the architecture and main components of the mITX-E38. The key ® component on the board is the Intel Atom E38xx SOC (Bay Trail). SODIMM DDR3L 1066/1333 1 slot 1-8GB. Intel DP (DisplayPort 1.1), LVDS (2 pixel/clock, 24 bit):...

  • Page 14: Integrated Premounted Cooler

    P/N 1055-9447: 4GB DDR3L 1600 PC3L-12800 P/N 1055-9448: 8GB DDR3L 1600 PC3L-12800 Note: Kontron has succesfully tested mITX-E38 in range -25⁰C to 75⁰C, but only 0⁰C to 60⁰C is guaranteed. Memory modules have in general a much lower longevity than embedded motherboards, and therefor EOL of modules can be expected several times during lifetime of the motherboard.

  • Page 15: Power Consumption

    KTD-N0903-C Page 13 System Specification Power Consumption The following items were used in the test setup: mITX-E38 Low Power Setup: Standard system configuration equipped with Internal graphics, 1x SATA disks, Intel E3815CPU , 1x SODIMM (2GB Module), DP Monitor, PS2 Keyboard & Mouse,1x 16GB USB 3.0 Stick, Passive heat-sink, +12V PSU.

  • Page 16: Connector Locations

    KTD-N0903-C Page 14 Connector Locations Connector Locations mITX-E38 – Frontside and Rear IO XDP (unsupported) (on backside) Clear CMOS SIM socket (on backside) COM2, COM1, COM3, COM4, COM6, COM5 Kbd/Mse USB4 USB5 FRONTPNL SODIMM FEATURE mPCIe USB6/7 mSATA & USB0 Always On SD Card Fan SOC...

  • Page 17: Connector Definitions

    KTD-N0903-C Page 15 Connector Definitions Connector Definitions The following sections provide pin definitions and detailed description of all on-board connectors. The connector definitions follow the following notation: Column Description name Shows the pin-numbers in the connector. The graphical layout of the connector definition tables is made similar to the physical connectors.

  • Page 18: Rear Io Connectors

    KTD-N0903-C Page 16 Rear IO Connectors Rear IO Connectors DC Power Jack Connector (Ext12V – J35) Either the DC Power Jack Connector (Ext12V) or the “Int12V.” connector must be used to supply the board with +12V +/-5%. The Ext12V power connector has Vin to the center pin and mates with Ø 6.3 mm DC Power jack with Ø 2.0 mm pin hole.

  • Page 19: Dp Connectors (Dp1 - J24, Dp2 - J22)

    KTD-N0903-C Page 17 Rear IO Connectors DP Connectors (DP1 – J24, DP2 – J22) The DP (DisplayPort) connectors are based on standard DP type Foxconn 3VD51203-H7JJ-7H or similar. Signal Description Type Note Lane 0 (p) LVDS Lane 0 (n) LVDS Lane 1 (p) LVDS Lane 1 (n)

  • Page 20: Usb Connectors (Io Area)

    KTD-N0903-C Page 18 Rear IO Connectors USB Connectors (IO Area) The mITX-E38 board contains support for one external USB3.0/2.0 port (USB3) and two external USB2.0 ports (USB1 and USB2). One USB2.0 port (USB0) is available via mPCIe slot. On the E3845 four extra internal USB2.0 ports are available via internal pin connectors USB6/7 connector and Front Panel connector (USB4/5).

  • Page 21: Usb Connector 1/2 (Usb1 / Usb2 - J6)

    KTD-N0903-C Page 19 Rear IO Connectors USB Connector 1/2 (USB1 / USB2 – J6) USB Ports 1 and 2 supports up to USB2.0. Note Type Signal Signal Type Note 1 2 3 4 DSIO-3.3 USB1- USB1+ DSIO-3.3 1 2 3 4 DSIO-3.3 USB2- USB2+ DSIO-3.3 Signal...

  • Page 22: Ethernet Connectors (Lan1 - J4 And Lan2 - J5)

    KTD-N0903-C Page 20 Rear IO Connectors Ethernet Connectors (LAN1 – J4 and LAN2 – J5) Two channels of 10/100/1000Mb Ethernet based on Intel® Pearsonville i211AT PCI Express controllers are available. In order to achieve the specified performance of the Ethernet port, Category 5 twisted pair cables must be used with 10/100MB and Category 5E, 6 or 6E with 1Gb LAN networks.

  • Page 23: Audio Jack Connectors (Speakers - J2, Line-In -J23)

    KTD-N0903-C Page 21 Rear IO Connectors Audio Jack Connectors (Speakers – J2, Line-In –J23) The on-board Audio circuit, based on VT1708S having UAA (Universal Audio Architecture) and featuring five 24-bit stereo DACs and three 20-bit stereo ADCs, implements up to 8 Channel High Definition Audio via two audiojack connectors located in the Rear IO area, the internal Feature pin-row connector, internal MIC1 pin-row connector, internal Headphone pin-row connector and via SPDIF.

  • Page 24: Internal Connectors

    KTD-N0903-C Page 22 Internal Connectors Internal Connectors DC Power Internal Connector (Int12V – J7) The mITX-E38 has an internal power input connector for supplying voltage in the range from +11.4V to +12.6V. The power connector is a 4 pin 12V ATX connector type Lotes ABA-POW-003-K02 or similar. Header Signal Description...

  • Page 25: Power Out Connector (Powerout - J32)

    KTD-N0903-C Page 23 Internal Connectors Power Out Connector (PowerOut - J32) The Power Out connector can be used to power source external devices like HDD. The connector is type Molex 22-23-2041 or similar. Header Signal Description Type Power +5V Ground Ground Power +12V Warning: Hot Plugging power supply is not supported.

  • Page 26: Internal Audio Connectors

    KTD-N0903-C Page 24 Internal Connectors Internal Audio Connectors The on-board Audio circuit implements 7.1+2 Channel High Definition Audio with UAA (Universal Audio Architecture), featuring five 24-bit stereo DACs and three 20-bit stereo ADCs. The following Audio connectors are available as internal connectors. Headphone Connector (Headphone –...

  • Page 27: Fan For Soc And System (Fan Soc - J29, Fan Sys - J28)

    KTD-N0903-C Page 25 Internal Connectors Fan for SOC and System (Fan SOC – J29, Fan Sys – J28) The Fan SOC is used for the connection of the FAN included in active SOC cooler. The Fan Sys can be used to power, control and monitor fan for chassis ventilation etc. Header Signal Description...

  • Page 28: Ps/2 Keyboard And Mouse Connector (Kbd/Mse) (J26)

    KTD-N0903-C Page 26 Internal Connectors PS/2 Keyboard and Mouse connector (KBD/MSE) (J26) Attachment of a PS/2 keyboard/mouse can be done through the pinrow connector KBD/MSE. Both interfaces utilize open-drain signalling with on-board pull-up. The PS/2 mouse and keyboard is supplied from 5V when in standby mode in order to enable keyboard or mouse activity to bring the system out from power saving states.

  • Page 29: Lvds Flat Panel Connector (Lvds - J31)

    KTD-N0903-C Page 27 Internal Connectors LVDS Flat Panel Connector (LVDS – J31) The LVDS connector is based on 40 pole connector type Samtec SHF-120-01-F-D-SM-K-TR or similar. Note Type Signal Signal Type Note Max. 0.5A +12V +12V PWR Max. 0.5A Max. 0.5A +12V +12V PWR Max.

  • Page 30: Sata (Serial Ata) Disk Interface (Sata0 - J15, Sata1 - J1)

    KTD-N0903-C Page 28 Internal Connectors SATA (Serial ATA) Disk interface (SATA0 – J15, SATA1 – J1) The two SATA ports available on the mITX-E38 supports SATA Gen2 (3.0/1.5Gb/s). Notes: RAID is not supported. SATA1 shared with mSATA, so that if mSATA is installed then the SATA1 is disabled.

  • Page 31: Internal Usb Connectors (Usb6/7 - J21)

    KTD-N0903-C Page 29 Internal Connectors Internal USB Connectors (USB6/7 – J21) USB Port 6 and 7 are supplied on the internal 10-pin- row connector USB6/7. Only available at E3845. Header Signal Description Type USB6_5V 5V protected by separate 1A resettable fuse USB7_5V 5V protected by separate 1A resettable fuse DSIO-3.3...

  • Page 32: Serial Com Ports (Com1-6, J19, J18, J37, J38, J10, J9)

    KTD-N0903-C Page 30 Internal Connectors Serial COM Ports (COM1-6, J19, J18, J37, J38, J10, J9) Six RS232 serial ports are available via 10-pin-row connectors. Note Ioh/Iol Type Signal PIN Signal Type Ioh/Iol Note PWR GND 9 10 PWR - The typical definition of the signals in the COM ports is as follows: Signal Description Transmitted Data, sends data to the communications link.

  • Page 33: Front Panel Connector (Frontpnl - J12)

    KTD-N0903-C Page 31 Internal Connectors Front Panel Connector (FRONTPNL - J12) 7.10 Pull Ioh/ Ioh/ Pull Note Type Signal Signal Type Note PWR USB4_5V USB5_5V PWR - USB4- USB5- USB4+ USB5+ PWR GND PWR - Headphone-L PWR 5V 11 12 PWR - 25/25mA O SATA_LED#...

  • Page 34: Feature Connector (Feature - J27)

    KTD-N0903-C Page 32 Internal Connectors Feature Connector (Feature – J27) 7.11 Note Pull U/D Ioh/Iol Type Signal Signal Type Ioh/Iol Pull U/D Note SMBCLK /4mA 10K/ 25/25mA O SMBDAT /4mA 10K/ 25/25mA O PWR_OK EXT_BAT PWR - PWR SB3V3 SB5V PWR - GPIO0 11 12...
  • Page 35 KTD-N0903-C Page 33 Internal Connectors The GPIO’s are controlled via the ITE IT8516F Embedded Controller. Each GPIO has 100pF to ground, clamping Diode to 3V3 and has multiplexed functionality. Some pins can be DAC (Digital to Analogue Converter output), PWM (Pulse Width Modulated signal output), ADC (Analogue to Digital Converter input), TMRI (Timer Counter Input), WUI (Wake Up Input), RI (Ring Indicator Input) or some special function.

  • Page 36: Clear Cmos Settings" (Clear Cmos - J3)

    KTD-N0903-C Page 34 Internal Connectors Clear CMOS Settings” (Clear CMOS – J3) 7.12 The Jumper has 3 positions: Pin 1-2, Pin2-3 (default position) and not mounted. pin 1 Warning Don’t leave the jumper in position 1-2, otherwise if power is disconnected, the battery will fully deplete within a few weeks.

  • Page 37: Always On Connector (Always On - J36)

    KTD-N0903-C Page 35 Internal Connectors Always On connector (Always On - J36) 7.13 The “Always On” can be used to implement hardware controlled Always ON by jumper. When “Always On” is selected, then the board will power up automatically when power is connected. It doesn’t matter if “Always On”...

  • Page 38: Spi Connector (Spi - J16)

    KTD-N0903-C Page 36 Internal Connectors SPI Connector (SPI – J16) 7.14 The mITX-E38 provides one synchronous full duplex SPI (Serial Peripheral Interface) Bus in a 10 pin header connector. The connector is type Pinrex 512-90-10GBE5 or similar. Two things should be considered: An onboard SPI flash coexists on the same interface lines.

  • Page 39: Lpc Connector (Lpc - J30)

    KTD-N0903-C Page 37 Internal Connectors LPC Connector (LPC - J30) 7.15 The LPC connector is in general unsupported (application wise). Only under special circumstances where the LPC interface is a must it will be possible by the customer to use this connector. Please notice that incorrect use of the interface may course system instability.

  • Page 40: Xdp Debug Port (Xdp - J40)

    KTD-N0903-C Page 38 Internal Connectors XDP Debug Port (XDP – J40) 7.16 The XDP-CPU (Intel Debug Port for CPU) connector is not mounted and not supported. XDP connector layout (pads) is located on the backside of PCB and is prepared for the Molex 52435-2671 (or 52435-2672). Signal Description Type Pull Up/Down Note...

  • Page 41: Slot Connectors

    KTD-N0903-C Page 39 Slot Connectors Slot Connectors The mITX-E38 has support for PCIex1, SD Card, mPCIe or mSATA inclusive USB2.0 and SIM support PCI-Express x1 Connector (PCIex1 – J8) The PCIex1 can be used for external PCI Express cards inclusive graphics card. Maximum theoretical bandwidth is 4 Gbps effectively for each direction, 8 Gbps in total.

  • Page 42: Mpcie/Msata Connector (Mpcie Or Msata & Usb - J13)

    KTD-N0903-C Page 40 Slot Connectors mPCIe/mSATA connector (mPCIe or mSATA & USB – J13) The mPCIe/mSATA connector supports mSATA or PCIe and USB 2.0 (USB0) and SIM socket cards. The mSATA port is shared with SATA1. Note Type Signal Signal Type Note WAKE#...

  • Page 43: Onboard - & Mating Connector Types

    Note: In above table, more than one connector can be listed for each type of on-board connector, if they all have same fit, form and function and are approved by Kontron as an alternative. Please notice that standard connectors like DP, PCIe, mPCIe, Audio Jack, Ethernet and USB are not included in the list.

  • Page 44: 10 Bios

    KTD-N0903-C Page 42 BIOS - Main 10 BIOS The BIOS Setup is used to view and configure BIOS settings for the board. The BIOS Setup is accessed by pressing the <Del>-key after the Power-On Self-Test (POST) memory test begins and before the operating system boot begins.

  • Page 45: System Information

    KTD-N0903-C Page 43 BIOS - Main System Information Phoenix SecureCore Technology Setup Main System Information BIOS Version BTI_3.1.0.314 X64 Build Time 08/25/2014 Processor Type Intel ® Atom ™ CPU E3826 @ 1.46GHz Processor Speed 1.474 GHz System Memory Speed 1066 MHz L2 Cache RAM 1024 KB Total Memory...

  • Page 46: Boot Features

    KTD-N0903-C Page 44 BIOS - Main Boot Features Phoenix SecureCore Technology Setup Main Boot Features Item Specific Help NumLock: [On] Select Power-on state for NumLock. Timeout [ 2] CSM Support [Yes] Quick Boot [Enabled] Diagnostic Splash Screen [Disabled] Diagnostic Summary Screen [Disabled] BIOS Level USB [Enabled]...
  • Page 47 KTD-N0903-C Page 45 BIOS - Main Function Selection Description NumLock: Select Power-on state for NumLock. 0,1,2, …99 Number of seconds that P.O.S.T will wait for the user Timeout input before booting. Note 1 Compatibility Support Module that provides backward CSM Support compatibility services for legacy BIOS services, like int10/int13, dependent OS.

  • Page 48: Error Manager

    KTD-N0903-C Page 46 BIOS - Main Error Manager Phoenix SecureCore Technology Setup Main Error Manager Item Specific Help View Error Manager Log [Enter] Display Error Manager Log information. Clear Error Manager Log [Enter] Help ↑↓ Select Item Change Values Setup Defaults Exit ←→...

  • Page 49: Advanced

    Values may cause the system to malfunction! Select Language [English] ► CPU Configuration ► Uncore Configuration ► LAN Configuration ► Hardware Health Configuration ► Kontron Configuration ► Display Configuration ► System Components ► South Cluster Configuration ► Security Configuration ► Thermal ► SMBIOS Event Log ►...

  • Page 50: Cpu Configuration

    KTD-N0903-C Page 48 BIOS - Advanced CPU Configuration Phoenix SecureCore Technology Setup Advanced CPU Configuration Item Specific Help CPU Configuration Execute Disable Bit prevent certain Execute Disable Bit [Enable] classes of mailicious buffer overflow AESNI [Enable] attacks when combined with a Limit CPUID Maximum [Disable] supporting OS.
  • Page 51 KTD-N0903-C Page 49 BIOS - Advanced CPU Power Management Phoenix SecureCore Technology Setup Advanced CPU Power Management Item Specific Help System Power Options Enable processor performance states Intel ® SpeedStep ™ [Enable] (P-States). Boot performance mode [Max Performance] Intel ® Turbo Boost Technology [Enable] C-States [Enable]...

  • Page 52: Uncore Configuration

    KTD-N0903-C Page 50 BIOS - Advanced Uncore Configuration Phoenix SecureCore Technology Setup Advanced Uncore Configuration Item Specific Help GOP Configuration Enable GOP Driver will unload GOP Driver [Enable] VBIOS; Disable it will load VBOIS. IGD Configuration Integrated Graphics Driver [Enable] Primary Display [Auto] RC6 (Render Standby)
  • Page 53 KTD-N0903-C Page 51 BIOS - Advanced Function Selection Description Auto Select the IGD Turbo feature, if Auto IGD Turbo Enable selected, IGD Turbo will only be enabled Disable when SOC stepping is B0 or above. Disabled Spread Spectrum clock Enable clock chip Spread Spectrum feature. Enable Force Lid Status For test: force to set lid status as on or off.

  • Page 54: Lan Configuration

    KTD-N0903-C Page 52 BIOS - Advanced LAN Configuration Phoenix SecureCore Technology Setup Advanced LAN Configuration Item Specific Help LAN Configuration Control the Ethernet Devices and PXE boot. ETH1 Configuration (Left) [Enabled] MAC Address & Link status : [00E0F42DDF76-] ETH2 Configuration (Right) [Enabled] MAC Address &...

  • Page 55: Hardware Health Configuration

    KTD-N0903-C Page 53 BIOS - Advanced Hardware Health Configuration Phoenix SecureCore Technology Setup Advanced Hardware Health Configuration Item Specific Help Hardware Health Configuration System Temperature [ 39ºC/102ºF] CPU Temperature [ 49.71ºC/121ºF] System Fan Speed [ 1286 RPM] System Temperature Ext Type [Disabled] Fan Cruise Control [Thermal]...
  • Page 56 KTD-N0903-C Page 54 BIOS - Advanced Function Selection Description Disabled (Note 1) System Temperature Ext Type Use external connected sensor instead of LM75 @ 0x90 onboard. OneWire @ GPIO16 Fan Cruise Control Disabled Disabled = Full speed. (System) Thermal Thermal: Regulate according to specified ºC. Speed Speed: Regulate according to specified RPM.

  • Page 57: Kontron Configuration

    KTD-N0903-C Page 55 BIOS - Advanced Kontron Configuration Phoenix SecureCore Technology Setup Advanced Kontron Configuration Item Specific Help Kontron Configuration Function for the mini PCIe slot. Mini PCIe slot [mPCIe] Help ↑↓ Select Item Change Values Setup Defaults Exit ←→...

  • Page 58: Display Configuration

    KTD-N0903-C Page 56 BIOS - Advanced Display Configuration Phoenix SecureCore Technology Setup Advanced Display Configuration Item Specific Help Display Configuration Enable/Disable onboard LVDS. Onboard LVDS [Enabled] Resolution [640 x 480] Manufacture [(Standard)] Panel name [640x480 18] Panel VCC [3,3V] Backlight Enable Active [Low] Help ↑↓...

  • Page 59: System Components

    KTD-N0903-C Page 57 BIOS - Advanced System Components Phoenix SecureCore Technology Setup Advanced System Components Item Specific Help Kontron Configuration Select PNP setting mode, Disable, Performance, Power or PNP Setting [Auto Detect] Power&Performance mode. Help ↑↓ Select Item Change Values...

  • Page 60: South Cluster Configuration

    KTD-N0903-C Page 58 BIOS - Advanced South Cluster Configuration Phoenix SecureCore Technology Setup Advanced South Cluster Configuration Item Specific Help ► PCI Express Configuration PCI Express Configuration Settings. ► USB Configuration ► Audio Configuration ► SATA Drives ► LPSS & SCC Configuration ►...
  • Page 61 KTD-N0903-C Page 59 BIOS - Advanced PCI Express Configuration Phoenix SecureCore Technology Setup Advanced PCI Express Configuration Item Specific Help PCIe 1 Speed [Gen1] Configure PCIe Speed. PCIe 2 Speed [Gen1] PCI Express Root Port 1 (PCIe x1) [Enable] PCI Express Root Port 2 (mPCIe) [Enable] Help ↑↓...

  • Page 62: Usb Configuration

    KTD-N0903-C Page 60 BIOS - Advanced USB Configuration Phoenix SecureCore Technology Setup Advanced USB Configuration Item Specific Help xHCI Mode [Disable] Mode of operation of xHCI controller. XHCI Link Power Management [Enable] To use DOS, enable EHCI and USB OTG Support [Disable] disable XHCI.

  • Page 63: Audio Configuration

    KTD-N0903-C Page 61 BIOS - Advanced Audio Configuration Phoenix SecureCore Technology Setup Advanced Audio Configuration Item Specific Help Audio Configuration Select LPE Audio ACPI mod eor PCI LPE Audio Support [Disable] mode. Audio Controller [Enable] Azalia VCi Enable [Enable] Azalia Docking Support Enable [Disable] Azalia PME Enable [Enable]...

  • Page 64: Sata Drives

    KTD-N0903-C Page 62 BIOS - Advanced SATA Drives Phoenix SecureCore Technology Setup Advanced SATA Drives Item Specific Help SATA Drives Enables or Disables the Chipset SATA Controller. The Chipset SATA Chipset-SATA Controller Configuration Controller supports the internal Chipset SATA [Enabled] SATA ports (up to 3Gb/s supported SATA Test Mode [Disable]...

  • Page 65: Lpss & Scc Configuration

    KTD-N0903-C Page 63 BIOS - Advanced LPSS & SCC Configuration Phoenix SecureCore Technology Setup Advanced LPSS & SCC Configuration Item Specific Help LPSS & SCC Devices Mode [PCI Mode] LPSS & SCC Devices Mode Settings. SCC Configuration SCC eMMC Boot Controller [Auto Detect] SCC eMMC Support [Enable]...
  • Page 66 KTD-N0903-C Page 64 BIOS - Advanced Disable eMMC HS200 SSC eMMC 4.5 HS200 Support Enable\Disable. Enable eMMC retune timer value (note1) 0,1,…8,…,15 Disable SCC SDIO Support SCC SDIO Support Enable\Disable. Enable Disable SCC SD Card Support SCC SD Card Support Enable\Disable. Enable Disable SD SDR 25 Support...

  • Page 67: Miscellaneous Configuration

    KTD-N0903-C Page 65 BIOS - Advanced Miscellaneous Configuration Phoenix SecureCore Technology Setup Advanced Miscellaneous Configuration Item Specific Help Miscellaneous Configuration Enable or Disable the High Precision High Precision Timer [Enable] Event Timer. Boot Time with HPET Timer [Disable] State after G3 [S0 State] Clock Spread Spectrum [Disable]...

  • Page 68: Security Configuration

    KTD-N0903-C Page 66 BIOS - Advanced Security Configuration 10.3 Phoenix SecureCore Technology Setup Advanced Security Configuration Item Specific Help TXE Configuration TXE FW Version 1.0.2.1067 TXE FW Capabilities 20001040 TXE FW Features 20001040 TXE FW OEM Tag 00000000 TXE Firmware Mode Normal TXE File System Integrity Value [Enable]...

  • Page 69: Thermal

    KTD-N0903-C Page 67 BIOS - Advanced Thermal Phoenix SecureCore Technology Setup Advanced Thermal Item Specific Help Thermal Configuration Parameters This value controls the temperature Critical Trip Point of the ACPI Critical Trip Point – the Passive Trip Point [85 C] point in which the OS will shut the system off.
  • Page 70 KTD-N0903-C Page 68 BIOS - Advanced Function Selection Description This value controls the temperature of the ACPI Critical Trip Point – the point in 15 C, 23C, 31 C, 39C, 47 (Thermal Configuration Parameters) which the OS will shut the system off. C, 55 C, 63 C, 71 C, 79 C, Critical Trip Point 85 C, 87 C, 90 C...
  • Page 71 KTD-N0903-C Page 69 BIOS - Advanced Disable Enable CLPM Current Low Power Mode. Application specific (note2) OS Level DPTF Processor Disable Enable/Disable Processor Participant Enable (note2) Device. Disable CPU Sensors Enable/Disable CPU Temperature Enable (note2) Sensors. Disable Ambient Sensors Enable/Disable Ambient Temperature (note2) Enable Sensors.

  • Page 72: Smbios Event Log

    KTD-N0903-C Page 70 BIOS - Advanced SMBIOS Event Log Phoenix SecureCore Technology Setup Advanced SMBIOS Event Log Item Specific Help Event Log Validity Valid Enable/Disable Event Log. Event Log Capacity Space Available Event Log [Enabled] ► View SMBIOS event log Mark SMBIOS events as read [Enable] Clears SMBIOS events...

  • Page 73: Memory Ecc Error Logging

    KTD-N0903-C Page 71 BIOS - Advanced Memory ECC Error Logging Phoenix SecureCore Technology Setup Advanced Memory ECC Error Logging Item Specific Help Error Logging [Enabled] Enable Memory ECC Error Logging Single-Bit [Enabled] to SMBIOS Event Log. Multi-Bit [Disabled] Help ↑↓ Select Item Change Values Setup Defaults...

  • Page 74: Security

    KTD-N0903-C Page 72 BIOS - Security Security 10.4 Phoenix SecureCore Technology Setup Main Advanced Security Boot Exit Item Specific Help Secure Boot Activation [Disabled] ► Secure Boot Configuration Set or clear the Supervisor Supervisor Password is: Cleared account’s password. User Password is: Cleared Set Supervisor Password [Enter]...

  • Page 75: Boot

    KTD-N0903-C Page 73 BIOS - Boot Boot 10.5 Phoenix SecureCore Technology Setup Main Advanced Security Boot Exit Item Specific Help Boot Priority Order 1. ATAPI CD: Keys used to view or configure 2. ATA HDD0: devices: ↑ and ↓ arrows Select a 3.

  • Page 76: Exit

    KTD-N0903-C Page 74 BIOS - Exit Exit 10.6 Phoenix SecureCore Technology Setup Main Advanced Security Boot Exit Item Specific Help Exit Saving Changes Exit Discarding Changes Equal to F10, save all changes of Load Setup Defaults all menus, then exit setup Load Optimized Defaults configure driver.
