Distance calculation module operating environment

The Distance module opens on the following window:
The FireReader 1D operating environment is organized into four areas:
1
1
2
The dash board contains five different tabs:
1. Detect
2. Analyse
3. Home
The image window displays the active image:
UVITEC – Cambridge
99/225
1. The dash board
2. The image window
3. The working window
3
