The option folder gathers the following functions:
Help
H
ELP MENU
Click on the "Help" button. You automatically access the user manual at the chapter
corresponding to the function
B – Edit band
The Edit band process follows the lane definition:
The edit band process automatically identifies all the bands for the defined lanes. You
can also manually mark the bands on the image or on the lane's profile. All bands will be
automatically detected when you first access the band detection process, based on
default parameters.
The bands are marked by green lines, overlaid on the gel image.
Note: you can either access the lane definition menu by clicking on the next button of the
lane definition or directly on the band detection tab.
