format – 16-bit format).
The OpenPlatform file format is a multi-layer based format which contained the image as displayed in
the software, the raw data image, the image settings and the GLP data.
In the standard 16-bit TIFF file format, the TIFF image contained only the raw data and the GLP
image data. The image is showed according to the software display preference. Other software use
other displays settings. Thus, the image showed in the image acquisition software could look like
different if opened in a Microsoft software for instance. The OpenPlatform file format provide an
alternative to this process thanks to a multi-layer approach.
OpenPlatform format with:
- one layer containing the displayed
image,
- one layer containing the RAW image
- and one layer containing the image data
The first slice of the layer is a bitmap image of the image as displayed in the acquisition software.
The second layer contains the raw image data.
The third image layer contains the image information for the acquisition software: GLP, displays
settings, ...
The OpenPlatform image format has the following advantages
- Respect of the image integrity
- Compatibility with other software platform
- Image information incorporated in the image file
- OpenPlatform image can be directly use for publication or reporting

Print

This function prints a previously opened image as it appears in the image window. Click on the "Print"
icon. A pop-up window displays the following menu:
UVITEC – Cambridge
177/225
Standard 16-bit TIFF image and GLP image
