UVITEC Cambridge FIREREADER MAX User & Service Manual page 115

This function allows the assignment of RF values to the detected bands. To do so, an origin
line and a front line must be defined. Usually the origin is set to value 0 and the front to 1,
but the FireReader 1D allows you to set your own values for origin and front lines.
Note: you can either access marker value menu by clicking on the next button of the band
detection or directly on marker value tab.
The dashboard details the marker values parameters:
Define the reference value
Define the front value
D
EFINE THE REFERENCE AND THE FRONT VALUES
An origin and a front line are displayed on the image:
UVITEC – Cambridge
115/225
