Control panel – FireReader D56 & D59 series
Main switch
The darkroom D56 & D59 main switch is located on the darkroom right hand side:
Darkroom right hand side
Switch on the main switch before to use the system.
Darkroom back side: power supply and optional USB motorized zoom lens connection
UVITEC – Cambridge
35/225
« POWER» switch
USB board
Optional : for Auto
versions
(motorized zoom
lens)
