UVITEC Cambridge FIREREADER MAX User & Service Manual page 109

The lanes are defined by green lines, overlaid on the gel image. The gel area is surrounded
by square anchors:
To resize the entire lane frame, drag an anchor point in or out. The opposite anchor point
will remain fixed while the frame expands or contracts. The frame will expand or contract
from the center.
To move the entire frame to a new position, position the mouse on the frame to obtain a
cross cursor:
Click and drag the cursor to move the entire frame.
Note: it is not necessary to include the well line in the area of interest window. The
calculation of molecular weight does not require this reference line.
L
ANE DIRECTION
Select the direction of the lanes from:
Horizontal
Or vertical
UVITEC – Cambridge
109/225
