A – Edit lane
The molecular weight module opens on the Edit lane dashboard of the Detect process:
The dashboard details the lane edition parameters:
Lane direction
Number of lanes
Gap between the lanes
A
REA OF INTEREST
On the image, click and drag to define the analysis area and to overlap the lanes. You can
easily adjust the size of the area by clicking on the tags surrounding the area and drag the
selected border to the requested size.
