Patch Independents

Independent buttons IND 1 and IND 2 provide two outputs separated from all other controls.
They are intended to operate devices such as smoke machines, tab tracks, cue lights, etc.
• SOLO does not affect these outputs.
• The state or result of the 2 independent outputs is not recordable.
The Default Patch
SmartFade defaults to the outputs 97 & 98 for the independents.
This is easy to remember and provides immediate control with two outputs. It is also
possible to create a custom patch by assigning any DMX outputs to the independents. This
is done in the Patch. They are indicated in the patch as channels i1 and i2.
Dimmer" on page 20. See "Patch by Channel" on page 21.
S e t u p I n d e p e n d e n t s
The basic behavior of the buttons and faders are set up in the Independents menu.
Menu>[Independents]
Button behavior
Menu choice
[Button mode]
[Master mode]
[Set Level]
22
IND 1 = DMX 97
IND 2 = DMX 98
Console
Use MENU to select inde-
pendent and the wheel to
select function
Use MENU to select inde-
pendent and the wheel to
select function
Use MENU to select inde-
pendent and the wheel to
set the level
Feedback
Sets if BLACKOUT and MASTER
fader will affect or not.
SmartFade v3.0.1 User Manual
See "Patch by
