P a t c h b y C h a n n e l
Patching by channel is just as simple as patching by dimmer. The only difference is that the
starting point is the intensity channel. By doing it Live you can check what is patched to
each intensity channel, and then patch or unpatch more dimmer outputs to this channel.
Step 1:
Step 2:
Step 3:
Step 4:
2
Setup
Open the Patch:
Menu>Patch>[Patch by Channel]
Choose between Live and Blind mode using the wheel.
Press (MENU) to confirm.
Use the wheel to select channel.
Press (MENU) to confirm and move to Dimmer. There are five dimmer positions
for each channel to allow you to patch more than one dimmer. If you select an
output that is already patched there is an "*" after the number as after dimmer 4
in the image below.
Now use the wheel to select a dimmer for this channel.
Press (MENU) to confirm and move through all five dimmer positions, back to
channels.
