A 1 – T
PPENDIX
Measurement Performance
Measurement principle
Range
* User may select any desired measurement from 0-100ppb, 0-10ppm, 0-1,00ppm [...] up to 0 - 20,000ppm
Accuracy
Repeatability
Response time
Operating Conditions
Process temperature
Process pressure
Process flow
Operational ambient temperature
Cleaning
Utilities
Power supply
Power frequency
Power consumption
Instrument air
Certification
Ingress protection
Enclosure material
Hazardous Areas:
IMO MEPC-107 (49)
Weight & Dimensions
Weight (including stand, pneumatic steel valve assembly,
termination box &
Dimensions
Clear space
Mounting
Communications
4-20 mA
Ethernet
HART, Modbus, Wireless (Wi-Fi), Extended Ethernet
Remote access
Internal data storage
Security
Additional Information
Flange fitting
Wetted parts
Sample take off point
Viewing window
Sample Conditioning
Maintenance
Gas removal, solids removal, temp. conditioning, flow control
Spectrometer Specification (EX-1000 models only)
Emission wavelength range
Resolution
8 Meadowbank Road, Carrickfergus, BT38 8YF, Northern Ireland
D
ECHNICAL ATA
Exd II 2 G IIB T4
isolation switch)
OIW-HBO-0002-EX-005
OIW EX SERIES-SIDE STREAM
OPERATION
R e v . 0 0 4 M A Y 2 0 1 5
Laser Induced Fluorescence (LIF)
0 - 20,000ppm
±1% of measurement range
> 99%
< 1 Second, continuous results
0°C to 200°C
0-35 barg (180 barg optional)
0-25 l/min (0 – 1000 l/min optional)
-20°C to 55°C
Ultrasonic (automatic)
110 or 230 VAC (pre configured)
50/60 Hz
60W normal, 300W peak
5-8 barg (for pneumatic valve; electric valve option available)
IP66
SS 316L or Aluminum
ATEX, IECEx, Class 1 Div 1 (USA and Canada)
IMO Certified, ABS, US Coast Guard, BV
Aluminium Enclosure: 93.55Kg
Stainless Steel Enclosure: 141Kg
670W x 640D X 1120H mm (1112H mm for Aluminum enclosure)
500mm front and rear
Optional stand or brackets
Passive
Standard
Optional
Standard
>10 years
Multiple level password protection
1" ANSI RF standard (optional flange, sizes available)
SS 316L(option of CR22, CR25, Monel, Inconel, Hastelloy, Titanium)
Standard ½" NPT
Standard
None - Automatic Cleaning
Not Required
400-1,100nm
0.5nm
