3.2.3.1.1.4 – Passwords
A password is required to make any configuration changes to the system and shutdown. Passwords for up to 7 users
can be created in the 'Passwords' menu shown below in Figure 48. A password must be a minimum of 4 characters in
length up to 9 characters. Characters can be any combination of letters, numbers or symbols.
access, selected from the drop down list, are available: Standard or Full. Standard access disables the change password
function and prevents editing of the ultrasonic settings and calibration parameters.
administrative and configuration access. Once the password parameters have been entered, select the 'Save New
Password' button and the information will be saved for the given user number.
commissioning or by Advanced Sensors Personnel.
NOTE: If an incorrect password is entered more than 3 times then a log will be written to the system log
3.2.3.1.1.5 – Help
The OIW Help feature can be enabled or disabled by selecting the 'Show Help' button in the 'Help' menu shown in Figure
49 below (left side image). Using the F10 key will also toggle the 'Help' on and off. When the cursor is held over a menu
option as shown in Figure 49 below (right side image) the help feature will provide basic information about available
features.
8 Meadowbank Road, Carrickfergus, BT38 8YF, Northern Ireland
Figure 48: Password set up menu.
file and (if enabled) an alarm will be raised.
Figure 49: Help menu.
OIW-HBO-0002-EX-005
OIW EX SERIES-SIDE STREAM
OPERATION
MANUAL
R e v . 0 0 4 M A Y 2 0 1 5
Two levels of user
Full access provides full
Passwords will be set up at
www.advancedsensors.co.uk
Page 42 of 93
