The remaining menu option is 'Auto Tuning', Figure 59. Auto tuning, as previously described in Section 2.3.4 — Phase
Auto Tuning, is a process that will automatically sweep through a defined frequency range to detect the optimal
operating and cleaning frequencies for the local temperature. Auto Tuning will always occur at the same point in the
measurement cycle. Auto tuning must be enabled and configured by an authorized Advanced Sensors Engineer or
Representative.
CAUTION: Adjustments to the ultrasonic system (for cleaning and homogenization) shall only be performed
8 Meadowbank Road, Carrickfergus, BT38 8YF, Northern Ireland
Figure 59: Auto tuning menu.
by Advanced Sensors trained or authorized personnel only. Excessive application of power to
the ultrasonic system may over time result in etching the measurement window and reduce the
expected working life of the transducer.
