Display System Logs on Screen: tick to enable and the multifunction 'System Logs' button will appear in the 'Alarm
Indicators' section of the 'Feedback Display Area'. The figures below show the system log display enabled and disabled.
Logs will still be recorded in the System Log file for traceability.
Cycle State on Power Up: Users have the choice of 3 options when powering up the analyzer:
1. Power Up in Stopped State: Requires the user to start the analyzer to begin the measurement cycle.
2. Power Up in Started State: The analyzer will start the measurement cycle automatically. A warning message
will open to alert the user that damage could occur if no water is present in the measurement chamber.
3. Power Up in Last Cycle State: The analyzer will power up in the previous operational state; i.e. will
automatically start if a measurement cycle was running prior to the power removal or will start up in a stopped
state if not previously running in a measurement cycle. A warning message will open to alert the user that
damage could occur if no water is present in the measurement chamber.
Auto Save and Logout Options: The system, by default, will remain logged in and idle for up to 1 hour. After 1 hour
the system will automatically save the current configurations and log the user out. An additional option allows the user
to extend the login period for 6 hours if required. The default option is fixed at 1 hour and will revert back to this default
after each logout.
8 Meadowbank Road, Carrickfergus, BT38 8YF, Northern Ireland
Figure 43: a. System logs display ENABLED
OIW-HBO-0002-EX-005
OIW EX SERIES-SIDE STREAM
OPERATION
R e v . 0 0 4 M A Y 2 0 1 5
b. System logs display DISABLED
