1.4 – E
LECTRICAL
1. The EX system is designed to operate off one of 2 nominal power variants: 115VAC or 230VAC.
2. It is the responsibility of the INSTALLER to ensure compliance with the regional requirements for electrical
safety regarding the provision of a compliant earth, earth bonding, adjacent electrical isolation and circuit
protection.
3. The enclosure shall be grounded via the external earth point, using an earth conductor, and once installation is
complete the system shall be inspected for compliance with regional requirements.
NOTE: Ensure the analyzer voltage and the supply voltages are compatible BEFORE commencing the
installation.
1.5 - M
ECHANICAL
1. The system - without the optional sunshade - weighs 93.5 kg (aluminium enclosure) or 141 kg (stainless steel
enclosure) (including the enclosure, stand, flow valve and Measurement Chamber). It is the customer's
responsibility to ensure appropriate H&S compliance for the movement and manual handling of this unit.
2. Ensure water is present in the measurement chamber at all times during the analytical cycle. Insufficient water
in the chamber may result in damage to the sapphire window and/or the automated cleaning system.
3. The measurement chamber assembly has been design tested to 150 bar. It is the customer's responsibility to
ensure that the process fluid pressure to the system does not exceed this level.
4. Installations where the process water temperature may be high it is the customer's responsibility to comply
with any regional H & S signage requirements.
CAUTION: The analyzer unit, including peripherals (i.e. measurement chamber, flow valve and stand), is
8 Meadowbank Road, Carrickfergus, BT38 8YF, Northern Ireland
S
AFETY
S
AFETY
heavy and weighs more than 90kg. To prevent injury, all movement of the analyzer shall
comply with local H & S procedures.
