BONFIGLIOLI HDP Series Manual page 172

M
HDP 130_160 42
HDP 130_180 48
HDP 130_200 55
HDP 130_225 60
HDP 130_250 65
HDP 130_280 75
HDP 130_315 80
HDP 140_160 42
HDP 140_180 48
HDP 140_200 55
60
HDP 140_225
65
HDP 140_250
75
HDP 140_280
80
HDP 140_315
HDP 150_160 42
HDP 150_180 48
HDP 150_200 55
HDP 150_225 60
HDP 150_250 65
HDP 150_280 75
HDP 150_315 80
HDP 160_160 42
HDP 160_180 48
HDP 160_200 55
HDP 160_225 60
HDP 160_250 65
75
HDP 160_280
80
HDP 160_315
170
M1 M2 N
45.3 12 350
51.8 14 350
59.3 16 400
64.4 18 450
69.4 18 550
79.9 20 550
85.4 22 660
45.3 12 350
51.8 14 350
59.3 16 400
64.4 18 450
69.4 18 550
79.9 20 550
85.4 22 660
45.3 12 350
51.8 14 350
59.3 16 400
64.4 18 450
69.4 18 550
79.9 20 550
85.4 22 660
45.3 12 350
51.8 14 350
59.3 16 400
64.4 18 450
69.4 18 550
79.9 20 550
85.4 22 660
N1 N2 N3
300 250 23
300 250 23
350 300 —
400 350 26
500 450 30
500 450 30
600 550 22
300 250 23
300 250 23
350 300 —
400 350 26
500 450 30
500 450 30
600 550 22
300 250 23
300 250 23
350 300 —
400 350 26
500 450 30
500 450 30
600 550 22
300 250 23
300 250 23
350 300 —
400 350 26
500 450 30
500 450 30
600 550 22
N4 X P
18 6 551
18 6 551
M16x23 7 576
18 7 583
18 6 613
18 6 613
22 10 649.5
18 6 551
18 6 551
M16x23 7 576
18 7 583
18 6 613
18 6 613
22 10 649.5
18 6 601
18 6 601
M16x23 7 626
18 7 633
18 6 663
18 6 663
22 10 699.5
18 6 601
18 6 601
M16x23 7 626
18 7 633
18 6 663
18 6 663
22 10 699.5
