BONFIGLIOLI HDP Series Manual page 171

M
HDP 100_112 28
38
HDP 100_132
42
HDP 100_160
HDP 100_180 48
HDP 100_200 55
HDP 100_225 60
65
HDP 100_250
HDP 100_280 75
HDP 100_315 80
HDP 110_112 28
38
HDP 110_132
HDP 110_160 42
HDP 110_180 48
HDP 110_200 55
HDP 110_225 60
65
HDP 110_250
HDP 110_280 75
HDP 110_315 80
HDP 120_132 38
42
HDP 120_160
HDP 120_180 48
HDP 120_200 55
HDP 120_225 60
65
HDP 120_250
HDP 120_280 75
HDP 120_315 80
M1 M2 N
31.3 8 250
41.3 10 300
45.3 12 350
51.8 14 350
59.3 16 400
64.4 18 450
69.4 18 550
79.9 20 550
85.4 22 660
31.3 8 250
41.3 10 300
45.3 12 350
51.8 14 350
59.3 16 400
64.4 18 450
69.4 18 550
79.9 20 550
85.4 22 660
41.3 10 300
45.3 12 350
51.8 14 350
59.3 16 400
64.4 18 450
69.4 18 550
79.9 20 550
85.4 22 660
N1 N2 N3
215 180 15
265 230 —
300 250 23
300 250 23
350 300 —
400 350 26
500 450 30
500 450 30
600 550 22
215 180 15
265 230 —
300 250 23
300 250 23
350 300 —
400 350 26
500 450 30
500 450 30
600 550 22
265 230 —
300 250 23
300 250 23
350 300 —
400 350 26
500 450 30
500 450 30
600 550 22
N4 X P
14 5 395
M12x20 6 415
18 6 481
18 6 481
M16x23 7 506
18 7 513
18 6 543
18 6 543
22 10 579.5
14 5 395
M12x20 6 415
18 6 481
18 6 481
M16x23 7 506
18 7 513
18 6 543
18 6 543
22 10 579.5
M12x20 6 430
18 6 496
18 6 496
M16x23 7 521
18 7 528
18 6 558
18 6 558
22 10 594.5
169
