5.21.6 Connection socket automation torch

TETRIX
DRIVE 4 ROB
only!
Pin assignment of the 19-pole automated welding torch connection socket (X53):
Pin Signal form Signal name circuit
Output
A
Output
B
Input
C
Output
D
Output
E
Output
F
Input
G
Input
H
Output
J
Output
K
Input
L
Input
M
Output
N
Output
P
R
Input
S
Output
T
Output
U
Output
V
*Feature only available for the cold wire versions.
099-000141-EW501
12.01.2016
B
C
P
D
R
E
F
Function
diagram
PE_Dyn. Connection for cable screen
BR KOLL1 Collision sensor emergency shut-down +24 V
BR KOLL2 Collision sensor emergency shut-down
0VB B reference potential
0VAC Gas relay reference voltage
Sensor voltage see "Sensor voltage" section
Gas test Gas test B
Low gas level Gas pressure switch signal
Gas relay 42 VAC gas relay supply voltage
+5 V tacho B* Tacho supply voltage
Z tacho B* Tacho signal channel Z
TB 0VAC Encoding for connected media separation box
Inching A* Inching A
0VA* A reference potential
Encoded Encoded to prevent mix-up with 19-pole interface for
automated welding
Y tacho B* Tacho signal channel Y
0V B* Tacho supply voltage
- motor B* - push drive supply voltage
+ motor B* + push drive supply voltage
Design and function
A
M
L
N
U
V
K
T
S
J
H
G
Figure 5-28
Interfaces
X53-
PE_Dyn.
2n2F
A
PE_Dyn. PE_Dyn.
B
BR KOLL1
C
BR KOLL2
D
0VB
E
0VAC
F
Fühlerspannung Fühlerspannung
G
Gastest
H
Gasmangel
J
Gasrelais
K
+5V Tacho B
L
Z Tacho B
M
TB 0VAC
N
Einfädeln A
P
0VA
R
codiert
S
Y Tacho B Y Tacho B
T
0V Tacho B
U
- Motor B - Motor B
V
+ Motor B + Motor B
67
