4 Machine description – quick overview
4.1

Front view

Item Symbol
1
2
3
COM
• Retrofitting option •
0
4
1
• Retrofitting option •
0
5
l
6
7
099-000141-EW501
12.01.2016
Machine description – quick overview
Description 0
Lifting lug
Machine control- See 4.3 Machine control (Mode RC - on) chapter
PC interface, serial (D-Sub connection socket, 9-pole)
Key switch for protection against unauthorised use
Position "1" > changes possible,
Position "0" > changes not possible.
- See 5.18 Protecting welding parameters from unauthorised access chapter
Main switch, machine on/off
Cooling air inlet
Machine feet
Figure 4-1
Front view
